Drivers · Standard

LED Driver 100W 12V Waterproof IP67 8.3A

EV-SNP-100-12

Power100 W

Output voltage12 V DC

Input voltage220–240 V AC

Operation modeConstant voltage

DimmingNon-dimmable

IP ratingIP67

Rated current8.3 A

Dimensions155.6 × 47.6 × 32.5 mm(6.13 × 1.87 × 1.28 in)

Sold through authorised distributors

About the EV-SNP-100-12.

The EV-SNP-100-12 is a 100 W constant-voltage LED driver with a 12 V DC output, sealed to IP67.

With its IP67-sealed build, it is built for outdoor installations and signage modules and LED strip.

Backing that up: AC input（220-240VAC), built-in active PFC function, using plastic shell. internal potting and compliance to worldwide safety.

Protections: Short circuit / Over voltage / Over temperature/Over load.

Where it works

IP67 sealed enclosure

12 V constant voltage
