Class 2 compliant constant-voltage drivers for North-American installs — 40–60 W at 12 or 24 V.
EV-SNPV-40-12 | EV-SNPV-40-24 | EV-SNPV-60-12 | EV-SNPV-60-24 | |
|---|---|---|---|---|
| Model code | EV-SNPV-40-12 | EV-SNPV-40-24 | EV-SNPV-60-12 | EV-SNPV-60-24 |
| Power | 40 W | 40 W | 60 W | 60 W |
| Output voltage | 12 V DC | 24 V DC | 12 V DC | 24 V DC |
| Rated current | 3.33 A | 1.67 A | 5 A | 2.5 A |
| Input voltage | 90–264 V AC | 90–264 V AC | 100–240 V AC | 100–240 V AC |
| IP rating | IP20 | IP20 | IP20 | IP20 |
| Dimensions | 156 × 17 × 50 mm (6.14 × 0.67 × 1.97 in) | 156 × 17 × 50 mm (6.14 × 0.67 × 1.97 in) | 159.9 × 18 × 57.8 mm (6.3 × 0.71 × 2.28 in) | 159.9 × 18 × 57.8 mm (6.3 × 0.71 × 2.28 in) |
| Operation mode | Constant voltage (CV) | |||
| Certifications | CESELV | |||
| Protections | Short-circuit · Open-circuit · Overload · Over-voltage · Over-temperature | |||
