Indoor triac-dimmable constant-voltage drivers for smooth phase dimming — 30–80 W at 12 or 24 V.
EV-SP-30-12US-TDM | EV-SP-30-24US-TDM | EV-SP-60-12US-TDM | EV-SP-60-24US-TDM |  EV-SP-80-12US-TDM |  EV-SP-80-24US-TDM | |
|---|---|---|---|---|---|---|
| Model code | EV-SP-30-12US-TDM | EV-SP-30-24US-TDM | EV-SP-60-12US-TDM | EV-SP-60-24US-TDM | EV-SP-80-12US-TDM | EV-SP-80-24US-TDM |
| Power | 30 W | 30 W | 60 W | 60 W | 80 W | 80 W |
| Output voltage | 12 V DC | 24 V DC | 12 V DC | 24 V DC | 12 V DC | 24 V DC |
| Rated current | 2.5 A | 1.25 A | 5 A | 2.5 A | 6.67 A | 3.33 A |
| Input voltage | 108–132 V AC | 108–132 V AC | 100–120 V AC | 100–120 V AC | 100–120 V AC | 100–120 V AC |
| Dimming | Triac | Triac | Triac | Triac | Triac | Triac |
| IP rating | IP20 | IP20 | IP20 | IP20 | IP20 | IP20 |
| Dimensions | 158 × 18.3 × 45.8 mm (6.22 × 0.72 × 1.8 in) | 158 × 18.3 × 45.8 mm (6.22 × 0.72 × 1.8 in) | 217.25 × 21.2 × 60.35 mm (8.55 × 0.83 × 2.38 in) | 217.25 × 21.2 × 60.35 mm (8.55 × 0.83 × 2.38 in) | 217.25 × 21.2 × 60.35 mm (8.55 × 0.83 × 2.38 in) | 217.25 × 21.2 × 60.35 mm (8.55 × 0.83 × 2.38 in) |
| Operation mode | Constant voltage (CV) | |||||
| Certifications | cULUL | |||||
| Protections | Short-circuit · Open-circuit · Overload | |||||
